.transitions

When sentinel detects a document has changed it runs transitions against the doc. These transitions can be used to generate a short form patient id or assign a report to a facility.

Configuration

By default all transitions are disabled. They can be enabled by configuring the transitions property to have a key with the transitions name and a truthy value. As of version 3.12.0 some transitions will partially run on the client for offline users. To opt out from client-side transitions, add a "client_side: false" property to the transition configuration.

{
  "transitions": {
    "a": { },
    "b": true,
    "c": { "disable": false },
    "d": { "disable": true },
    "e": { "client_side": false }
  }
}

In the example above, the d transition will not be applied, a, b c will be applied on the server and on the client, while e will only be applied on the server.

Available transitions

The following transitions are available and executed in order.

Below are guides to setup specific transitions.

multi_report_alerts

Send alert messages by SMS when specific conditions are received through reports. More flexible than simple Alerts.

Example: send SMS to the district manager when 2 CHWs within the same district report cholera or diarrhea symptoms within the last week.

Understanding the different types of reports used in the configuration:

             previous suspected_cholera alert was sent
             |
             |           latest_report comes in, suspected_cholera alert is sent
             |           |
             v           v
---[---*-o---*--*--o-o---*]------->    time
                1        0

[] : time window

* and o : reports : any report that came in to the server.

* : counted_reports : reports that came in that passed the is_report_counted filter function.

0, 1 : new_reports : counted_reports that came in since the previous alert was sent. They haven’t been messaged about yet.

Configuration

"multi_report_alerts" : [
  {
    "name": "suspected_cholera",
    "is_report_counted": "function(report, latest_report) {  return latest_report.contact.parent.parent._id === report.contact.parent.parent._id; }",
    "num_reports_threshold": 2,
    "message": "{{num_counted_reports}} patients with {{alert_name}} in {{time_window_in_days}} days reported at {{new_reports.0.contact.parent.name}}. New reports from: {{new_reports.0.contact.name}}, {{new_reports.1.contact.name}}, {{new_reports.2.contact.name}}.",
    "recipients": [
      "+123456",
      "new_report.contact.phone", // sender of each report in new_reports
      "new_report.contact.parent.parent.contact.phone", // contact person for the parent place of the sender of each report in new_reports.
      // If it's the same for several reports, only one message will be sent (recipient phone numbers are deduplicated before generating messages).
    ],
    "time_window_in_days": 7,
    "forms": ["C", "D"] // Only Cholera and Diarrhea forms.
  }
]

Note that we are using Mustache templates for our message templates (anything with {{}}), and they use a . notation to access items in an array (e.g. new_reports.1) rather than a [] notation as in conventional javascript (new_reports[1]).

For performance reasons the num_reports_threshold cannot exceed 100.

death_reporting

Updates patient documents with a date_of_death field which updates how the patient is displayed in the UI.

Configuration

Configuration is stored in the death_reporting field of the settings.

Example

"death_reporting": {
  "mark_deceased_forms": [ "death" ],
  "undo_deceased_forms": [ "undo-death" ],
  "date_field": "fields.death_date"
}

registration

Configuration is held at app_settings.registrations, as a list of objects connecting forms to validations, events and messages.

Events

Lists different events.

on_create

This is the only supported event.

Triggers

add_patient

Sets the patient_id on the root of the registration document and creates the person doc if required. Can be configured to either use a provided ID or generate a new unique one.

External Patient ID

If you are providing the patient ID instead of having Sentinel generate you one, name the field in a patient_id_field key in "params":

{
    "name": "on_create",
    "trigger": "add_patient",
    "params": "{\"patient_id_field\": \"external_id\"}",
    "bool_expr": ""
}

In this example the provided ID would be in fields.external_id on the registration document. This field must not be called patient_id.

{
    "params": {"patient_id_field": "external_id"},
}

Alternative Name Location

To provide an alternative location for the patient name, either provide a patient_name_field in "params" or provide it directly into the "params" field as a String:

{
    "params": "{\"patient_name_field\": \"full_name\"}",
}

{
    "params": "full_name",
}

The first format is required if you wish to also provide other params:

Contact Type

If you have changed from the default contact hierarchy you will need to specify which type of contact the registration should create.

{
    "params": "{ \"contact_type\": \"patient\" }"
}

Specific Parent as of 3.8.0

By default, the newly created person will have the same parent as the report submitter. A different parent may be selected by providing a location for the parent id. This field should contain the place_id of the place in question. If the selected parent is invalid - does not exist or does not respect the configured hierarchy

• the report is rejected as invalid and the person document is not created. As such , report_accepted event should check if the report has a patient property (or similar).

 {
     "params": "{ \"parent_id\": \"parent_id\" }"
 }

Events

• parent_field_not_provided - triggered when the report does not have the required parent_id field
• parent_invalid - triggered when selected parent is invalid (parent document is found and either does not have a configured type or its type is not configured to be a parent to the person type to be created)
• parent_not_found - triggered when selected parent is not found

The selected parent (if found) can be accessed by using the parent path in error messages: Cannot create a person type "patient" under parent {{parent.place_id}}({{parent.contact_type}})

add_patient_id

Deprecated in favour of add_patient. Previously this only added a patient_id to the root of the registration form. This functionality has been merged into add_patient. Now, using this event will result in the same functionality as described in add_patient above.

add_expected_date

add_birth_date

assign_schedule

clear_schedule

add_place as of 3.8.0

Sets the place_id on the root of the registration document and creates the place doc with the provided type.

By default, the created place would have the same parent as the submitter. If such a combination is invalid - for example a contact under a “clinic” attempts to create a new “health_center” - the report will be rejected as errored and the place document will not be created. As such, report_accepted event should check if the report has a place property (or similar).

The created place does not have a primary contact. The created place can be accessed by the place path in messages: Place {{place.name}}({{place.place_id}}) added to {{place.parent.name}}({{place.parent.place_id}})

Contact Type

Specifying the contact type is required, even if not using configurable hierarchies. The selected contact type must be a configured place type.

{
    "params": "{ \"contact_type\": \"clinic\" }"
}

Specific Parent

By default, the newly created place will have the same parent as the report submitter. A different parent may be selected by providing a location for the parent id. This field should contain the place_id of the place in question. If the selected parent is invalid - does not exist or is not an acceptable parent to the selected type in the configured hierarchy - the report will be rejected as errored.

 {
     "params": "{ \"parent_id\": \"parent_id\" }"
 }

Events

• parent_field_not_provided - triggered when the report does not have the required parent_id field
• parent_invalid - triggered when selected parent is invalid (parent document is found and either does not have a configured type or its type is not configured to be a parent to the place type to be created)
• parent_not_found - triggered when selected parent is not found

The selected parent (if found) can be accessed by using the parent path in error messages: 'Cannot create a place type "health_center" under parent {{parent.place_id}}({{parent.contact_type}})'

Alternative Name Location

The created place’s name is provided in the place_name field by default. To provide an alternative location for the place name, provide a place_name_field in "params":

{
    "params": "{\"place_name_field\": \"clinic_name\"}",
}

add_case as of 3.9.0

Sets the case_id on the root of the registration document.

generate_shortcode_on_contacts

There is no custom configuration for generate_shortcode_on_contacts.

generate_patient_id_on_people

Deprecated since 3.8.x in favor of generate_shortcode_on_contacts

There is no custom configuration for generate_patient_id_on_people.

update_notifications

Deprecated in favor of Muting

Configuration

"notifications": {
    "off_form": "OFF",
    "on_form": "ON",
    "validations": {
      "join_responses": true,
      "list": []
    },
    "messages": [
      {
        "translation_key": "",
        "event_type": "on_mute",
        "recipient": "reporting_unit"
      },
      {
       "translation_key": "",
        "event_type": "on_unmute",
        "recipient": "reporting_unit"
      },
      {
        "translation_key": "",
        "event_type": "patient_not_found",
        "recipient": "reporting_unit"
      }
    ]
  }

muting

Implements muting/unmuting of persons and places. Supports multiple forms for each action, for webapp and sms workflows.

Muting action

Updates the target contact and all its descendants, setting the muted property equal to the current date in ISO format.

Client-side

Added in 3.12.0

Client-side muting runs offline on a user’s device. Only the contacts and reports available on the device will be updated.

• Sets the muted property on the target contact and all its descendants to the device’s current date (the moment the report is processed).
• Adds/updates the muting_history property on every updated contact, to keep track of all the updates that have been processed client-side, as well as the last known server-side state of the contact and sets the last_update property to client_side
• Updates the report doc to add a client_side_transitions property to track which transitions have run client-side

Server-side

Server-side muting runs as a typical Sentinel transition. Contacts that are already in the correct state are skipped. This applies to updates to the contact itself, updates to the Sentinel muting_history and to the connected registrations (registrations of a contact that is already in the correct state will not be updated).

• Sets the muted property on the target contact and all its descendants to the moment Sentinel processed the muting action.
  • If the contact was already muted by a client, the muted date will be overwritten. The client-side muting_history will have a copy of the client-side muting date.
• Adds a muting_history entry to Sentinel info docs for every updated contact
• Updates all connected registrations (for the target contact and descendants), changing the state of all unsent scheduled_tasks to muted
  • Unsent scheduled_tasks have either a scheduled or pending state
• Updates the contact’s client-side muting_history to set the last_update property to server_side and update the server_side section with the current date and muted state.
• If the report was processed client-side, all “following” muting/unmuting events that have affected the same contacts will be replayed. This means the transition could end up running multiple times over the same report.
  • Replaying is required due to how PouchDB <-> CouchDB synchronization does not respect the order in which the documents have been created, to ensure that contacts end up in the correct muted state.

Unmuting action

Updates the target contact’s topmost muted ancestor and all its descendants, removing the muted property. Because the muted state is inherited, unmuting cascades upwards to the highest level muted ancestor. If none of the ancestors is muted, unmuting cascades downwards only.

Client-side

Added in 3.12.0

Client-side unmuting runs offline on a user’s device. Only the contacts and reports available on the device will be updated.

• Adds/updates the muting_history property on every updated contact, sets the last known server-side state of the contact and sets the last_update property to client_side
• Updates the report doc to add a client_side_transitions property to track which transitions have run client-side

Server-side

Server-side unmuting runs as a typical Sentinel transition. Contacts that are already in the correct state are skipped. This applies to updates to the contact itself, updates to the Sentinel muting_history and to the connected registrations (registrations of a contact that is already in the correct state will not be updated).

• Adds a muting_history entry to Sentinel info docs for every updated contact
• Updates all connected registrations (for the target contact and descendants), changing the state of all present/future scheduled_tasks (ones due today or in the future) with the muted state to have the scheduled state.
  • All scheduled_tasks with a due date in the past will remain unchanged.
• Updates the contact’s client-side muting_history to set the last_update property to server_side and update the server_side section with the current date and muted state.
• If the report was processed client-side, all “following” muting/unmuting events that have affected the same contacts will be replayed. This means the transition could end up running multiple times over the same report.
  • Replaying is required due to how PouchDB <-> CouchDB synchronization does not respect the order in which the documents have been created, to ensure that contacts end up in the correct muted state.

Muting history

Server-side muting history

Each time the muted state of a contact changes, an entry is added to a muting_history list saved in Sentinel info docs (stored as an array property with the same name). Entries in muting_history contain the following information:

Client-side muting history

Added in 3.12.0

Each time the client changes the muted state of a contact, an entry is added to a muting_history property on the contact’s doc. The last_update entry is also changed to client_side. The muting_history property contains the following information:

Configuration

Configuration is stored in the muting field of app_settings.json.

Supported events_types are:

Example

"muting": {
    "mute_forms": ["mute_person", "mute_clinic"],
    "unmute_forms": ["unmute_person", "unmute_clinic"],
    "validations": {
      "join_responses": true,
      "list": []
    },
    "messages": [
      {
        "translation_key": "",
        "event_type": "mute",
        "recipient": "reporting_unit"
      },
      {
        "translation_key": "",
        "event_type": "unmute",
        "recipient": "reporting_unit"
      },
      {
        "translation_key": "",
        "event_type": "already_muted",
        "recipient": "reporting_unit"
      },
      {
        "translation_key": "",
        "event_type": "already_unmuted",
        "recipient": "reporting_unit"
      },
      {
        "translation_key": "",
        "event_type": "contact_not_found",
        "recipient": "reporting_unit"
      }
    ]
  }

accept_patient_reports

Allow reporting about patient and place centric workflows by

• validating the report
• assigning the relevant subject (patient or place) to the report if a registration with the given shortcode (patient_id or place_id) exists
• clearing messages on the registration
• generating response messages on the report

Example

"transitions": {
  "accept_patient_reports": true
},
"registrations": [{
  "form": "P",
  "events": [{
    "name": "on_create",
    "trigger": "assign_schedule",
    "params": "ANC Reminders",
    "bool_expr": "!doc.fields.last_menstrual_period || !(/^[0-9]+$/.test(doc.fields.last_menstrual_period))"
  }]
}],
"schedules": [{
  "name": "ANC Reminders",
  "translation_key": "schedule.anc_no_lmp",
  "summary": "",
  "description": "",
  "start_from": "reported_date",
  "messages": []
}],
"patient_reports": [{
  "form": "pregnancy_visit",
  "silence_type": "ANC Reminders",
  "silence_for": "8 days",
  "fields": [],
  "validations": {},
  "messages": [{
    "translation_key": "messages.pregnancy_visit",
    "event_type": "report_accepted",
    "recipient": "clinic"
  }]
}]

accept_case_reports

Allow reporting about case centric workflows by

• validating the report configuration documentation,
• assigning the relevant place to the report if a registration with the given case_id exists,
• clearing messages on the registration, and
• generating response messages on the report.

Example

"registrations": [{
  "form": "8",
  "events": [{
    "name": "on_create",
    "trigger": "add_case"
  }]
}],
"accept_case_reports": [{
  "form": "SIGNOFF",
  "validations": {},
  "messages": [{
    "event_type": "report_accepted",
    "bool_expr": "some expression",
    "message": "some message",
    "recipient": "some recipients"
  }]
}]

self_report

Updates a data_record to set its patient to its sender. The resulting doc will have fields.patient_uuid and fields.patient_id filled with the sender’s information. Provides hydrated patient information to subsequent transitions. The sender is the contact associated with the phone number that sent the original SMS.
If a doc already contains a patient field, does not have a sender or its form is not configured to be enabled for this transition, it will be ignored.

Configuration

Configuration is stored in the self_report field of app_settings.json as a list of objects connecting forms to messages. Every object should have this structure:

Supported events_types are:

Example

"self_report": [
  {
    "form": "FORM",
    "messages": [
      {
        "event_type": "report_accepted",
        "recipient": "reporting_unit",
        "translation_key": "messages.form.report_accepted"
      },
      {
        "event_type": "sender_not_found",
        "recipient": "reporting_unit",
        "translation_key": "messages.form.sender_not_found"
      }
    ]
  },
  {
    "form": "OTHER",
    "messages": [
      {
        "event_type": "report_accepted",
        "recipient": "reporting_unit",
        "translation_key": "messages.other.report_accepted"
      },
      {
        "event_type": "sender_not_found",
        "recipient": "reporting_unit",
        "translation_key": "messages.other.sender_not_found"
      }
    ]
  }
]

update_clinics

Adds a contact’s info to a data record so as to attribute an incoming SMS message or report to the appropriate contact.

Configuration

As of version 3.12 you can add configuration to send a message whenever a contact match fails while running this transition. Configuration is stored in the update_clinics field of app_settings.json as a list of objects connecting forms to messages. Every object should have this structure:

Supported events_types are:

If this configuration is not set then the message defaults to what is set in the messages.generic.sys.facility_not_found key.

Example

"update_clinics": [
  {
    "form": "FORM",
    "messages": [
      {
        "event_type": "sys.facility_not_found",
        "recipient": "reporting_unit",
        "translation_key": "sys.facility_not_found"
      }
    ]
  },
  {
    "form": "OTHER",
    "messages": [
      {
        "event_type": "sys.facility_not_found",
        "recipient": "reporting_unit",
        "translation_key": "messages.other.facility_not_found"
      }
    ]
  }
]

create_user_for_contacts

Users are automatically created for certain contacts. Both creating a new user for a new contact and replacing an existing user with a new user are supported.

Configuration

Several configurations are required in app_settings to enable the create_user_for_contacts transition.

Login by SMS must be enabled by setting the token_login configuration.

The app_url property must be set to the URL of the application. This is used to generate the token login link for the new user.

Example

"app_url": "https://demo.app.medicmobile.org",
"token_login": {
  "enabled": true,
  "translation_key": "sms.token.login.help"
},
"transitions": {
  "create_user_for_contacts": true
}

When adding a new person contact, the create_user_for_contacts transition can be triggered to create a new user associated with that contact. Available since 4.2.x.

Example scenario

A supervisor can onboard a CHW just by creating a new person contact for the CHW with a “create contact” form.

Once the new contact is synced with the server and has been processed by Sentinel, a user will be automatically created and the new CHW will receive an SMS message (at the phone number specified in the contact) containing a token login link. This link will allow them to login as the newly created user. For security reasons, the token login link is valid for only one use and can only be used within 24 hours.

Form Configuration

When the create_user_for_contacts transition is enabled, Sentinel will attempt to create a user for any newly created person contacts with the user_for_contact.create field set to 'true'. So, contact forms and app forms for adding persons that should trigger new user creation need to include a user_for_contact group that contains a create field. The calculation for the value of the create field should evaluate to 'true' when a new user is desired. Any other value for that field will not trigger user creation.

Once Sentinel has generated a user for the contact, the user_for_contact.create field will be automatically removed from the contact document.

Users are only generated for newly created contacts. Editing an existing contact will not trigger user creation regardless of the value set for the user_for_contact.create field.

Required contact fields

The new person contacts must have the following fields set:

• name
• phone - must be set to a valid number
• roles - must contain the desired roles for the new user (if just a single role is needed, the role field on the contact may be used instead)

See the person-create contact form provided in the Default config as an example. This form will trigger the creation of a new user for the contact when the role is set to chw or chw_supervisor and a phone number is provided.

Replace User

An existing offline user can be replaced on a device so that a new user can use that device without needing to immediately sync with the server. Available since 4.1.x.

Example scenario

Imagine a CHW is leaving the program, and the CHW’s device is returned to their supervisor. The supervisor wants to transfer the device to a new CHW immediately without having the device online to sync with the server.

To do this, when the create_user_for_contacts transition is enabled, the supervisor would submit a configured user replacement form for the original user’s contact on the device. This form can create a new contact for the new CHW and will trigger a client-side transition to mark the original contact as replaced. After that, the supervisor can give the device to the new CHW, and they can begin using it.

Subsequent reports submitted on the device by the new CHW will be associated with the new contact. When the device is eventually able to synchronize with the server, it will be automatically logged out so the transition to the new user can be completed. A server-side transition will be triggered to initialize the new user for the new CHW. An SMS message containing a token login link will be sent to the new CHW allowing them to login as the initialized user. The password for the original user will be automatically reset by the server-side transition causing any remaining sessions for the original user (e.g. on other devices) to be logged out.

Details

This process does not actually delete the original user, but just resets the password to a random value. To recover the original user, a server administrator should update the user’s password to a known value or re-issue a token login link for the user (if enabled).

Because the server-side transition immediately invalidates any remaining sessions for the original user, it is not recommended to use this process for replacing users that are logged in on multiple devices simultaneously. The data on the device used to replace the user will always be completely synchronized before the user is replaced. However, un-synced data from other devices can be left on those devices when the user is replaced using a separate device.

replace_forms Configuration

User replacement via the create_user_for_contacts transition is triggered by submitting a configured app form for the original user’s contact.

The IDs of the app forms that should trigger the transition must be configured in the create_user_for_contacts.replace_forms array in the app_settings.

Then, the actual forms must set the replacement_contact_id property to the id of the contact that should be associated with the new user.

These forms should only be submitted for the original user’s contact. You can control the form visibility by including user._id === contact._id in the form properties expression.

These forms should only be accessible to offline users (replacing online users is not currently supported). This is the default in the example app form properties file (see replace_user.properties.json).

You can prevent a user from being replaced multiple times by including !contact.user_for_contact || !contact.user_for_contact.replace in the form properties expression. (This expression is not recommended for situations where multiple users can be associated with the same contact since replacing one of the users would prevent any of the other users for that contact from accessing the form.)

See the replace_user app form provided in the Default config as an example.

Example app_settings

"create_user_for_contacts": {
  "replace_forms": [
    "replace_user"
  ]
}

Troubleshooting

Configuration is validated when Sentinel starts. Issues with the configuration will be show in the Sentinel logs.

Errors occurring during the client-side transition will be recorded in the browser’s console. This is where problems with processing reports from the replace forms will be logged.

Errors occurring during the server-side transition will be recorded in the Sentinel logs and on the contact doc for the original user. So, if the client-side transition marks the original user for replacement, but Sentinel fails to create the new user, the failure will be recorded on the original contact doc in the errors array.

Related Content
